Product Description

l Substrate: UV Fused Silica

l Wavelength Range: 700 nm-1100 nm

l Application: Imaging, Beam Expansion or Reduction, Light Convergence

     Tuniu plano-convex lenses feature positive focal lengths and are commonly used in imaging and beam collimation applications. They are manufactured from RoHS-compliant UVFS glass and are primarily used in the UV and near-infrared regions. All Tuniu circular lenses come pre-mounted in standard lens tubes or lens mounting adapters. These mechanical components are engraved with the model number, type, diameter, and focal length, allowing users to quickly identify lens specifications.

Attributes

Plano-Convex (PCX) Lenses, UV Fused Silica, AR Coating: 700-1100nm, Mounted

l Mounted in Mechanical Housing or Unmounted

     Tuniu plano-convex lenses are made from UV fused silica glass, which offers improved homogeneity and a lower thermal expansion coefficient than N-BK7 glass. They are primarily used in the UV and near-infrared regions. They have a positive focal length and are often used in imaging or beam collimation applications. Tuniu mounted lenses are mounted in standard lens tubes, which are engraved with the model number, type, diameter, and focal length for quick identification.
