Product Description
l Optical Material: UV Fused Silica
l Application: Beam Deflection
l Operating Wavelength: 300 nm-1650 nm
Reflectors are used to change the direction of light beam emission. Tuniu's fused silica broadband dielectric coating mirrors achieve a reflectivity of over 99% within the working wavelength range. To meet customers' diverse size requirements, Tuniu offers UV fused silica dielectric mirrors in various shapes including round, oval, square, and D-shaped. Tuniu also provides customized reflector services with other materials and coating systems. For customization needs, please contact our technical support.
Attributes
Broadband Dielectric Mirrors, Circular
l Working Wavelength: 300 nm-750 nm, 400 nm-750 nm, 750 nm-1100 nm, 1100 nm-1650 nm
The reflector is used to change the direction of the light beam. Tuniu's fused silica broadband dielectric coating achieves a reflectivity of over 99% within the working wavelength range. To meet various size requirements from customers, Tuniu offers UV fused silica dielectric mirrors in multiple sizes, including Ø12.7 mm, Ø25.4 mm, and Ø50.8 mm. Additionally, Tuniu provides customized services for reflectors with other materials and coating systems. For customization needs, please contact technical support.
Broadband Dielectric Mirrors, Elliptical·
l Operating Wavelength: 400 nm-750 nm, 750 nm-1100 nm, 1100 nm-1650 nm
The reflector is used to change the direction of the light beam. Tuniu's fused silica broadband dielectric coating achieves a reflectivity of over 99% within the working wavelength range. To meet customers' diverse size requirements, Tuniu offers UVFS dielectric mirrors in various shapes including round, oval, square, and D-shaped. Tuniu also provides customized services for dielectric-coated fused silica reflectors. For customization needs, please contact our technical support.
Broadband Dielectric Mirrors, Square
l Operating Wavelength: 400 nm-750 nm, 750 nm-1100 nm, 1100 nm-1650 nm
The reflector is used to change the direction of the light beam. Tuniu's fused silica broadband dielectric coating achieves a reflectivity of over 99% within the working wavelength range. To meet customers' diverse size requirements, Tuniu offers UVFS dielectric mirrors in various shapes including round, oval, square, and D-shaped. Tuniu also provides customized services for dielectric-coated fused silica reflectors. For customization needs, please contact our technical support.
Broadband Dielectric Mirrors, D-shaped·
l Operating Wavelength: 400 nm-750 nm, 750 nm-1100 nm, 1100 nm-1650 nm
Tuniu broadband dielectric-coated D-shaped mirrors are available in various coating types, with the coating covering the entire reflective surface. The coating wavelength ranges include 400 nm-750 nm, 750 nm-1100 nm, and 1100 nm-1650 nm. They are suitable for selecting one beam from two closely spaced beams. Additionally, the backside of the mirror's straight edge features a wedge-shaped cut with a 45° angle, facilitating beam splitting for diverging or converging light.
